Himiway A7 Pro Full Suspension Commuter E-Bike | 500W Mid-Drive

·  Navigate city streets with unparalleled style and efficiency on the Himiway A3 Urban Electric Commuter Bike. Designed for the modern rider, this sleek electric city bike combines powerful performance with intelligent features, making every journey a pleasure. Experience the future of urban mobility with its long-lasting battery, intuitive pedal assist, and durable construction.

More

·  Performance & Range: Powering your ride is a silent yet mighty 500W brushless geared hub motor, delivering an impressive 86Nm of torque to conquer hills and headwinds effortlessly. The Himiway A3 offers a remarkable 70-mile range on a single charge thanks to its integrated 48V 15Ah LG/Samsung lithium battery. With a quick 5-hour charge time, you're always ready for your next adventure.

Intelligent Riding Experience: Equipped with an advanced torque sensor, the Himiway A3 provides a natural and responsive pedal assist, seamlessly matching your effort for a truly intuitive ride. Its Shimano Altus 7-speed drivetrain offers versatile gearing for varied terrain, while Tektro hydraulic disc brakes ensure superior stopping power and safety in all conditions.

·  Urban Design & Comfort: The Himiway A3 boasts a unique unibody frame construction that integrates the battery for a clean, minimalist aesthetic and enhanced frame strength. 26" x 2.2" Innova tires and a front suspension fork absorb road vibrations, ensuring a comfortable and smooth ride. Features like integrated LED lights, full fenders, and an adjustable kickstand make it the perfect electric bike for daily commuting.

·  Customization: With 28 mounting points throughout its frame, the Himiway A3 allows for extensive customization. Add a rear rack, basket, child seat, or other accessories to perfectly tailor your urban e-bike to your specific needs.

Specs

Geometry

Recommended Height: 5'1"~6'

A – total length 70.6 B - handlebar height 45.3 C – wheelbase 43.8 D – minimum seat height 24 E – maximum seat height 31.8 F – chain stay length 18.3 G – frame stack 23.5 H – effective top tube length 21.1

I – wheel diameter 26.2 J – head tube length 8.5 K – handlebar length 26.7 L – frame reach 16.4 M – head angle 69° N – standover height 24.6

Specification

Frame	6061 Aluminum frame
Headset	Neco A16M 44*44*30
Fork	6061 aluminum 100*12mm thru axle, rack mounts, fender mounts, post disc mount
Front wheel	Rim: 26""*1.75*36H*13G A/V | Spoke: 13G*257.5MM/259.5MM | Hub: R303F-12 12g*36H 12*100mm
Rear wheel	Rim: 26""*1.75*36H*13G A/V | Spoke: 13G*225.5MM/226.5MM | Hub: 48v 500w Himiway Hub Motor
Tires	Innova IA-2128 26*2.2 25-60PSI
Battery	48V15AH LG 21700 IP65 720Wh
Motor	500w Himiway brushless gear motor
Display	Himiway LED Display
Sensors	Torque sensor丨speed sensor丨brake sensor
Crankset	Crank arm:J6061-T6 170mm | Chain ring: 38T narrow wide steel chainring BCD104
Chain	KMC Z8.3 EPT 112L
Groupset	Shimano altus M310 7 speed
Front brake	Tektro HD-E3520 hydraulic brake
Rear brake	Tektro HD-E3520 hydraulic brake
Rotors	F:160mm R:160mm

Components

Handlebar	Himiway integrated handlebar-Stem 680mm width*90mm stem
Seatpost	Himiway flip seatpost 27.2*300
Saddle	TTZ032X
Pedal	Aluminum pedal
Lights	48V LED light
Kickstand	Adjustable aluminum kickstand

Others

Range	70 miles
Controller	48V/18A
Charger	US standard 2.0 A smart charger
Rider height	5'1"~6'
Weight	68.3 lb.
Max. payload capacity	300 lb.
